NFC 20-130 dies for intercable AP130-C battery-powered hydraulic crimping tool
Compliant with standard NFC 20-130 – from 6 to 400 mm²
| Reference | mm² | W2 |
|---|---|---|
| NF6-C | 6 | 9 |
| NF10-C | 10 | 9 |
| NF16-C | 16 | 9 |
| NF25-C | 25 | 9 |
| NF35-C | 35 | 9 |
| NF50-C | 50 | 12 |
| NF70-C | 70 | 12 |
| NF95-C | 95 | 12 |
| NF120-C | 120 | 12 |
| NF150-C | 150 | 12 |
| NF185-C | 185 | 12 |
| NF240-C | 240 | 12 |
| NF300-C | 300 | 12 |
| NF400-C | 400 | 5 |
Compliant with standard NFC 20-130 – from 6 to 400 mm²
The NFC 20-130 crimping dies for AP130-C ensure dimensional and mechanical compliance of copper and aluminum connections according to the French reference standard. Designed for the intercable AP130-C battery-powered hydraulic crimping tool, they guarantee precise, repeatable crimping that meets the requirements of construction sites subject to quality control and regulatory audits.
intercable NFC 20-130 intercable AP130-C crimping dies guarantee full compatibility with certified lugs and sleeves.
Technical characteristics of NFC 20-130 dies
Characteristics of intercable NFC 20-130 intercable AP130-C crimping dies
- Compatibility: AP130-C and STILO60
- Cross-section range: 6 to 400 mm²(copper and aluminum).
- Profile and geometry compliant with standard NFC 20-130: dimensions, imprint, penetration depth, mechanical tolerances.
- Material: heat-treated high-strength steel, uniform hardness on active imprint.
- Engraved identification for workshop traceability and periodic inspection.
Advantages of certified intercable dies
- Immediate regulatory compliance for public contracts and industrial sites subject to NFC 20-130.
- Tooling compatibility: direct mounting on AP130-C without adapter, short cycles and uniform closure.
- Dimensional repeatability: precision machining and batch control guaranteeing crimping torque stability.
- Traceability and maintenance: die tracking via maintenance log and simple recalibration.
Why choose NFC 20-130 dies for the AP130-C
The combination of an intercable AP130-C hydraulic crimping tool and NFC 20-130 certified dies guarantees full crimping compliance according to French specifications: geometry, pressure and proof of conformity. This tool/die combination optimizes electrical safety, connection reliability and on-site productivity.
Main specifications
| Reference | mm² | W2 |
|---|---|---|
| NF6-C | 6 | 9 |
| NF10-C | 10 | 9 |
| NF16-C | 16 | 9 |
| NF25-C | 25 | 9 |
| NF35-C | 35 | 9 |
| NF50-C | 50 | 12 |
| NF70-C | 70 | 12 |
| NF95-C | 95 | 12 |
| NF120-C | 120 | 12 |
| NF150-C | 150 | 12 |
| NF185-C | 185 | 12 |
| NF240-C | 240 | 12 |
| NF300-C | 300 | 12 |
| NF400-C | 400 | 5 |
Best practices and compliance
- Verify die/lug correspondence before each crimping series.
- Maintain dies within their dimensional tolerance through periodic inspection.
- Train operators in correct AP130-C head alignment for uniform crimping.
Discover all intercable crimping solutions for copper and aluminum conductors.
