HFP12-HFP14/22-HFP3/16: Connectable Foot Pumps

BAUDAT single or double acting foot pumps, connectable to hydraulic cable cutters and STAMP cylinders. Compact solutions with anti-tipping plate, available in several capacities.

Industry type

Electrical networks

Brand

Baudat

Request a quote

Request a quote, we will get back to you within N days

Request a quote

HFP12-HFP14/22-HFP3/16: Connectable Foot Pumps

Robust equipment

Time savings

Local after-sales support

Operational safety

Description

BAUDAT HFP Foot Pumps are available in single or double acting versions; and can be connected directly with hydraulic Cable Cutters or STAMP cylinders.

BAUDAT HFP12 foot pumps: singleacting

Force: 40 kp at 450 bar
Operating pressure: 450 bar
Usable oil volume: 70 cm3
Flow rate: approximately 1,0 cm3/course
Length: 340 mm
Weight: approximately 3,4 kg
Connection M16 X 1.5 external thread with conical seat 24°
Anti-tipping support plate

BAUDAT HFP14/22 foot pumps: double acting

Force: 36 kp at 450 bar
Operating pressure: 450 bar
Usable oil volume: 250 cm3
Flow rate:
- Low pressure range up to approximately 2 bars: approximately 5,0 cm3/course
- High pressure range from 2 bars: approximately 2,0 cm3/course
Length: 400 mm
Weight: approximately 4 kg
Female quick coupling CEJN 115 series M16 X 1.5
Anti-tipping support plate

BAUDAT HFP3/16 foot pumps: double acting

Operating pressure: 450 bar
Usable oil volume: 1600 cm3
Flow rate:
- Low pressure range: approximately 80 bars: approximately 19,7 cm3/course
- High pressure range: approximately 450 bars: approximately 3,2 cm3/course
Length: 530 mm
Weight: approximately 12 kg
Female quick coupling CEJN 115 series M16 X 1.5
Anti-tipping support plate

Compatible with BAUDAT hydraulic Cable Cutters
